The LEACH solid-state power controller（SSPC）We have adopted the latest microcontroller and Power FET technology, which has been integrated into surface mounted printed circuit boards (PCBs). EPM-110 SSPC has stepless switching function for all types of loads, while preventing overload and short circuit. It has extensive built-in testing (BIT) capabilities that can verify all critical functions during startup and operation. It is designed to operate in a 28 VDC system and has two fully rated 40 Amps channels. Size: 91 x 91 x 23 millimeters Weight: Maximum 150 grams

EPM-110 Product Features:

2-channel rated current from 40 amperes to 85 ° C

Power on continuous drill bit

Serial Data Bus Interface

Programmable rated values (25%, 50%, and 75% of rated values) and trip parameters

No bounce switch

Quick response

Low voltage drop and power consumption

Software based additional configuration design

万彩网100线路High voltage isolation

No derating of lamps, motors, and inductive loads

万彩网100线路Application parameters:

万彩网100线路Serial control and monitoring capability

Replace the electromechanical relay

Continuous drill bit

Load Status Report

No bouncing

万彩网100线路Long lifespan and high reliability

Overload trip

Programmable rating

If you need detailed technical parameters, please contact the technical personnel
