High precision - Dynamic self calibration peak detection differential Hall gear sensor - Supplier [Weikewei]

ATS616LSG gearsensorIt is a peak detection device that uses automatic gain control and integrated capacitors to achieve extremely high accuracy in tooth edge detection performance even at low speeds. ATS616LSG dualhall sensor The circuit is integrated together to respond to the differential magnetic field signal generated by the iron like target, and its internal circuit uses an A/D converter to correct the internal gain, minimizing the impact caused by gap changes. In addition, its patented peak detection filter circuit eliminates the misalignment between the magnet and the system, and can detect relatively fixed changes such as gear tilt, sway, and eccentricity, and can operate stably at extremely low rotational speeds.

万彩网100线路Main features:

● Self calibration with high timing accuracy

● First tooth inspection

● Resistance to gap changes and system imbalance effects

● Eliminate the influence of marking teeth

Integrated capacitors provide simulated peak valley information

Extremely lowTiming accuracydrift

● Large work gaps

● Small external dimensions

The best magnetic circuit

万彩网100线路● Under voltage locking

● Wide working temperature range
